Modern ships operate with increasingly powerful engines and complex auxiliary systems, which generate continuous vibration during operation. If not properly controlled, these vibrations can lead to pipeline fatigue, equipment instability, excessive noise, and reduced service life.
The TS Movable Elastic Hanger is specifically designed to address these challenges. It provides both flexible support and effective vibration isolation, making it an essential component in marine engineering and shipboard piping systems.
What is the TS Movable Elastic Hanger?
The TS Movable Elastic Hanger is a vibration isolation support device used in marine and industrial environments. It is designed to suspend pipelines or equipment while absorbing vibration and allowing controlled movement caused by thermal expansion or dynamic loads.
Its structure combines durable metal components with elastic elements, ensuring both strength and flexibility. This allows it to perform reliably under continuous vibration conditions.
Why Vibration Isolation is Critical in Ships
Shipboard equipment is constantly subjected to multiple sources of vibration, including:
- Diesel engine operation
- Propeller-induced excitation
- Wave and hull interaction forces
- Rotating machinery such as pumps and compressors
Without proper isolation, these vibrations can transfer through the ship structure, causing:
- Increased noise levels in engine rooms
- Structural fatigue in pipelines and supports
- Loosening of fasteners and connections
- Reduced reliability of onboard systems
To ensure safe operation, marine equipment typically follows vibration standards such as:
MIL-STD-167-1 – Mechanical Vibrations of Shipboard Equipment
Typical Shipboard Applications
The TS Movable Elastic Hanger is widely used across various ship systems.
Shipboard Pipeline Systems
It is primarily used in:
- Fuel pipelines
- Hydraulic pipelines
- Seawater cooling pipelines
- Exhaust piping systems
- HVAC duct and piping systems
The hanger supports pipeline loads while allowing movement and reducing vibration transmission.
Marine Diesel Generator Sets
In generator systems, the hanger helps isolate vibration from connected piping, preventing stress concentration and extending system life.
Marine Pump Systems
Applicable to:
- Seawater pumps
- Cooling pumps
- Ballast pumps
- Bilge pumps
It reduces vibration impact on connected pipelines and improves sealing reliability.
Auxiliary Machinery and Equipment
Also suitable for:
- Compressors
- Ventilation systems
- Engine room auxiliary equipment
These systems benefit from reduced vibration transmission and improved operational stability.
Key Performance Features
The TS Movable Elastic Hanger offers:
- Combined support and vibration isolation
- Ability to accommodate thermal expansion and displacement
- Stable performance under dynamic loads
- Suitable for medium and high-speed diesel engine environments
- Durable structure for harsh marine conditions
- Long service life and low maintenance
Maximum Load: 2000 kg
Technical Characteristics
- Rated Vertical Load (N): Customizable
- Vertical Deflection under Rated Load (mm): Designed for elastic performance
- Natural Frequency (Hz): Optimized for vibration isolation
- Damping Ratio: Stable energy dissipation
- Vibration Test Standard: Complies with MIL-STD-167-1
- Adjustable Length: Allows flexible installation
Advantages Over Traditional Supports
Compared with rigid hangers, the TS Movable Elastic Hanger provides:
- Reduced vibration transmission to ship structures
- Improved pipeline safety and durability
- Compensation for thermal expansion
- Lower noise levels in engine rooms
- Increased reliability of connected equipment
Conclusion
The TS Movable Elastic Hanger is a practical and reliable solution for vibration isolation and flexible support in marine systems. It is widely used in shipboard pipelines, diesel generator systems, pumps, and auxiliary equipment.
With its combination of strength, flexibility, and vibration control capability, it plays a critical role in improving the safety, efficiency, and longevity of modern ship systems.
